Name: Gigabyte X870E Aorus Master WIFI Motherboard
Brand: Gigabyte
SKU: MC-2443-WZ7H
Price: 48790 INR
Availability: InStock

Description
Reviews (0)

Category	Specification
CPU Support	AMD Socket AM5, supporting: - AMD Ryzen™ 9000 Series Processors - AMD Ryzen™ 8000 Series Processors - AMD Ryzen™ 7000 Series Processors * For latest CPU support, refer to GIGABYTE's website
Chipset	AMD X870E
Memory	4 × DDR5 DIMM slots, up to 256 GB (64 GB per DIMM) Supported speeds: DDR5 8600(OC) → 4400 MT/s Dual-channel architecture Supports ECC & non-ECC Un-buffered DIMMs Supports AMD EXPO™ & XMP memory modules * CPU and memory configuration may affect supported types and speeds; see "Memory Support List" on GIGABYTE's website
Onboard Graphics	Integrated AMD Radeon™ Graphics + ASMedia USB4® Controller: - 2 × USB4® Type-C® (DisplayPort, max 3840x2160@240Hz) - 1 × HDMI port (max 4096x2160@60Hz, HDMI 2.1, HDCP 2.3, HDR) - 1 × Front HDMI port (max 1920x1080@30Hz, HDMI 1.4) * Graphics specs may vary depending on CPU support
Audio	Realtek® ALC1220 CODEC DSD audio support, DTS:X® Ultra High Definition Audio: 2/4/5.1/7.1-channel S/PDIF Out supported * Audio jack functionality configurable via software
LAN	Realtek® 5GbE LAN (5/2.5/1/0.1 Gbps)
Wireless & Bluetooth	Qualcomm® Wi-Fi 7 QCNCM865 802.11 a/b/g/n/ac/ax/be, 2.4/5/6 GHz Bluetooth 5.3 Supports 11be 320MHz wireless standard * Wi-Fi 7 requires Windows 11 SV3; 6 GHz band availability depends on country
Expansion Slots	CPU-integrated: - 1 × PCIe x16 (PCIEX16) slot, PCIe 5.0 x16 (Ryzen 9000/7000) * Shares bandwidth with M2B_CPU & M2C_CPU; operates at x8 when populated - Ryzen 8000 Series-Phoenix 1: PCIe 4.0 x8 - Ryzen 8000 Series-Phoenix 2: PCIe 4.0 x4 Chipset: - 1 × PCIe x16, PCIe 4.0 x4 (PCIEX4_1) - 1 × PCIe x16, PCIe 3.0 x4 (PCIEX4_2)
Storage	CPU-integrated M.2: - 1 × M2A_CPU: PCIe 5.0/4.0/x4/x2 SSDs - 2 × M2B_CPU & M2C_CPU: PCIe 5.0/4.0 x4/x2 SSDs (unavailable with Ryzen 8000) Chipset M.2: - 1 × M2D_SB, PCIe 4.0 x4/x2 4 × SATA 6Gb/s RAID: NVMe RAID 0/1/5/10, SATA RAID 0/1/10 * RAID 5 only on Ryzen 9000
USB	CPU + ASMedia USB4®: 2 × USB4® Type-C® (back panel) CPU: 1 × USB 3.2 Gen2 Type-A (red, back panel) Chipset: - 1 × USB Type-C® Gen 2x2 (internal) - 3 × USB 3.2 Gen2 Type-A (red, back panel) - 8 × USB 3.2 Gen1 (4 back, 4 internal) - 6 × USB 2.0/1.1 (2 back, 4 internal)
Internal I/O	1 × 24-pin ATX 2 × 8-pin ATX 12V 1 × CPU fan header 1 × CPU fan/water pump header 4 × system fan headers 2 × system fan/water pump headers 4 × Addressable RGB Gen2 headers 1 × RGB header 4 × M.2 sockets 4 × SATA 6Gb/s Front panel, audio, USB Type-C w/ Gen2x2, 2 × USB 3.2 Gen1, 2 × USB 2.0/1.1, noise detection, TPM, HDMI, power/reset buttons, reset & Clear CMOS jumpers, 2 × temp sensors, voltage measurement points
Back Panel	Q-Flash Plus button, Clear CMOS button 1 × HDMI 2 × USB4® Type-C® (DisplayPort) 4 × USB 3.2 Gen2 Type-A (red) 4 × USB 3.2 Gen1 2 × USB 2.0/1.1 1 × RJ-45 2 × antenna connectors (2T2R) 2 × audio jacks 1 × optical S/PDIF Out
I/O Controller	iTE® I/O Controller Chip
H/W Monitoring	Voltage, Temperature, Fan Speed, Water Flow Detection, Fan Fail Warning, Fan Speed Control, Noise Detection * Fan/pump speed control depends on installed device
BIOS	256 Mbit flash, AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0
Unique Features	GIGABYTE Control Center (GCC) Q-Flash, Q-Flash Plus, Smart Backup * GCC app availability varies by motherboard model
Bundle Software	Norton® Internet Security (OEM) LAN bandwidth management software
Operating System	Windows 11 64-bit
Form Factor	ATX (30.5 × 24.4 cm)
Warranty	3 Years
Note	Price, features, and specifications subject to change without notice.
